| Additional Information |
Features
- 5.4 amp, 620 watt motor for rapid results in common 5/32" and 3/16" diameter holes
- Mode selector dial (drill-only and hammer-drilling) for flexibility within a range of applications
- 4.2 lbs and 11.4" in length, Hitachi's lightest and most compact SDS hammer for greater ease of use and maneuverability
- Quick bit insert for easy accessory changes
- Slip clutch prevents damage to gears caused by excessive torque
- Idle strike restrictor prevents hammering while tool is in no-load operation, prolonging tool life and reducing no-load vibration
- Internal pressure adjustment minimizes variations in internal pressure for stable hammering operation and efficient drilling
- Push button reverse switch to back out bits with ease
- Lock-on speed button to reduce user fatigue during continuous operation
- Removable side handle with ruled depth gauge improves control and ensures accurate drilling depth
Specifications
| Bit Type |
SDS Plus |
| Chuck Size |
7/8" |
| Amps |
5.4 |
| Impact Energy |
1.0 ft/lbs |
| Capacity: Concrete |
7/8" |
| Capacity: Steel |
1/2" |
| Capacity: Wood |
1" |
| No-Load Speed |
0-1,500 RPM |
| Impact Speed |
0-6,200 BPM |
| Modes |
2 |
| Power Input |
620 W |
| Handle Type |
Pistol |
| Length |
11.4" |
| Weight |
4.2 lbs |
Includes
- Side Handle (324548)
- Case (327883)
Contact us for warranty information |
