| Additional Information |
Features
- Powerful 7-amp motor delivers 2.1 ft.lbs. of impact energy to handle the most demanding applications
- L.E.D. light illuminates drilling surface for more productivity in low light applications
- Sequential impact timing delivers timed hammering during rotation to minimize overlapping bit impacts for up to 50% faster drilling
- Torque limiting clutch engineered to prevent gear damage by automatically disengaging gears if the bit binds
- 3-mode operation for Rotation Only, Hammering with Rotation or Hammering Only
- No hammering when idling function helps increase tool life
- Ergonomic "L-shaped" handle with rubberized soft grip for increased comfort and control
- Recessed lock-on button for continuous operation
- One-touch sliding chuck for quick bit changes
- Extended life brushes are longer for more work between service intervals and less downtime
- Makita motor advantage engineered with field core interlocking steel laminations, dual ball bearing armature and more copper commutator bars, increasing energy transfer efficiency for more power and longer tool life
Specifications
| Amperage (amps) |
7 |
Assembled Depth (in.) |
16.540 in |
| Assembled Height (in.) |
13.07 in |
Assembled Width (in.) |
4.53 in |
| Blows per Minute |
4500 |
Certifications and Listings |
1-UL Listed,CSA Listed |
| Chuck Size |
1-1/8 In. |
Chuck Type |
SDS-Plus |
| Clamshell/Jam pot |
Neither |
Color Family |
Teal |
| Cord Length (ft.) |
13 |
Corded Tool Type |
Hammer Drill |
| Cordless/Corded |
Corded |
Drill/ Driver Type |
Hammer Drill/ Driver |
| Forward/reverse switch |
Forward switch and reverse switch |
Maximum hole diameter (in.) |
3.125 |
| Maximum Speed (rpm) |
1100 |
Product Depth (in.) |
16.54 in |
| Power Tool Product Type |
Corded |
Product Weight (lb.) |
7.7 |
| Product Height (in.) |
13.07 in |
Reconditioned |
No |
| Product Width (in.) |
4.53 in |
Side Handle Included |
Yes |
| Variable Speed |
Yes |
Includes
- Side handle
- Depth gauge
- Tool case
Contact us for warranty information |
