Features
- Largest Crown Molding Cutting Capacity in its Class
- Powerful 15.0 AMP direct drive motor requires less maintenance and delivers 3,200 RPM
- Compact design with a patented 4-Steel Rail Sliding System further increases rigidity to produce superior cuts
- Exclusive 6 linear ball bearings engineered to deliver "dead-on" accurate cuts
- Increased capacity for up to 6-5/8" crown molding (vertically nested), 4-3/4" baseboard (vertical), and 12" crosscuts at 90°
- Miters 0°-52° left and 0°-60° right, with positive stops at 0°, 15°, 22.5°, 31.6°, and 45° (left and right)
- Less weight (53.3 lbs.) and the most compact design in its class for easy jobsite portability
Specifications
| Blade Diameter |
|
10" |
| Arbor |
|
5/8" |
| Crown Molding (nested) |
|
6-5/8" |
| Baseboard (vertical) |
|
4-3/4" |
| Max Cutting Capacity (Bevel/Miter) |
90°/90° |
2-13/16" x 12" |
| |
45°/45° L/R |
2-13-/16" x 8-1/2" |
| No Load Speed |
|
3,200 RPM |
| AMPS (120V) |
|
15 |
| Dimensions (LxWxH) |
|
28-1/4" x 25-1/4" x 26-1/2" |
| Net Weight (lbs.) |
|
53.3 |
Includes
- 60T Carbide Tipped Blade (A-93675)
- Vertical Vise (122854-6)
- Dust Bag (122852-0)
- Triangular Rule (762001-3)
- Socket Wrench #13 (782232-8)
- Hex Wrench (783208-8)
Contact us for warranty information |
