Features
- Adjustable laser marker for precise cutting lines easily adjustable to users preference
- 12 Amp motor, intense power for the toughest cutting jobs
- 57 Degree miter angle, to the right for ultra flexibility with 45 degree miter angle to the left
- 45 Degree bevel angle range, to the right and left allowing users to quickly and easily flip the saw blade and leave the material in place
- Positive stops on miter and bevel scale, for easy to read measurements and quick settings
- Linear ball bearing slide system, for superior accuracy and control
- Electronic speed control, maintains RPM while cutting and improves control
- Electronic soft start feature, suppresses sound pressure and recoil during start-up for smooth operation
- Adjustable pivot fence, broadly supports work piece for improved stability while cutting
- Electric brake feature, halts the rotation of the blade within seconds preventing unintended cuts
- Chip deflector, fully adjustable to prevent tear-out, align cutting line or for zero clearance support
- Carbon brush access, allows user to replace brush as needed to greatly prolong the life of the tool
- Dust collector attachment, minimizes airborne particles
- Splinter guard, prevents material from splintering and increases safety
Specifications
| Amps |
12 |
| No-Load Speed |
3,800 RPM |
| Blade Diameter |
10" |
| Arbor Size |
5/8" |
| Bevel Angle Range: R & L |
0-45 Degrees |
| Bevel Stops: Right and Left |
0 Degrees and 45 Degrees |
| Miter Angle Range: Right |
0-57 Degrees |
| Miter Angle Range: Left |
0-45 Degrees |
| Miter Detent Stops: Right and Left |
0 Degree, 15 Degrees, 22.5 Degrees, 31.6 Degrees and 45 Degrees |
| Tool Height |
24-1/4" |
| Weight |
43 lbs |
Includes
- 10" 40T TCT Saw Blade (310878)
- Pivoting Flip Fence (321385)
- 10mm Box Wrench (940543)
- Dust Bag (322955)
Contact us for warranty information |
