Features
- Revolutionary compact slide system allows the saw head to slide along fixed rails, eliminating the need for rear clearance
- Top-mounted, digital, LCD scale swivels to provide clear and accurate miter and bevel readings from any angle
- Laser marker system from Hitachi increases cutting accuracy
- Powerful 15 Amp motor with 1,850 Watts of max output power to tackle tough cutting jobs with ease
- Micro miter and micro bevel adjustment knobs to dial-in to precise angles
- Large pivoting fence raises fence height to 4-11/16 inches to cut crown molding vertically
- 0-57 degree miter angle to the right for flexibility with 0-46 degree miter angle to the left
- 0-45 degree bevel angle to the right and left allowing users to quickly and easily flip the saw blade and leave the material in place
- Positive stops on the miter and bevel scale, for easy to read measurements and quick settings
- Carbon brush access, allows the user to replace the brush as needed to greatly prolong tool life
- Vertical handle with soft, vibration reducing elastomer grip adds comfort and control
Specifications
| Compound Cut 45x45 (L/L) |
2-3/4"x8-5/8" or 2-15/16"x7-1/16" |
| Amps |
15 |
| No-Load Speed |
3,800 RPM |
| Blade Diameter |
12" |
| Miter Cutting Range |
0-46 Degree L; 0-57 Degree R |
| Bevel Cutting Range |
Left & Right 0-45 Degree |
| Digital Display |
Yes |
| Laser Marker |
Yes |
| Saw Blade Drive System |
Poly V Belt & Gear |
| Splinter Guard |
Provided (Fixed) |
| Tool Dimension WxDxH |
23-7/16"x36-5/8"x27-15/16" |
| Tool Weight |
66.1 lbs |
| Cutting Capacities (HxW): |
...................... |
| 90 Degree Cross Cut |
4-3/16"x12-1/4" or 4-11/16"x10-3/16" |
| 45 Degree Miter (L/R) |
4-3/16"x8-5/8" or 4-11/16" x7-1/16" |
| 45 Degree Bevel (L) |
2-3/4"x12-1/4" or 2-15/16" x10-3/16" |
Includes
- 12 inch 32T TCT Saw Blade (726100)
- Dust Bag (322955)
- Vice Assembly (324378)
- 17mm Box Wrench (985051)
Contact us for warranty information |
