Rotary Hammer Drill

Product Information

Item SKU

Hilti TE30

Item Name

Rotary Hammer Drill

Additional Information

Features

Superior working comfort: perfect balance, low weight, compact design and low vibration
Ruggedly built from high-grade materials and components for unbeaten, extra-long lifetime
Choice of chucks available, can be changed quickly without need for tools
Drilling anchor holes and through-holes in concrete and masonry, diameter range 4 – 28 mm, recommended range 8 – 20 mm
Drilling in wood with 10 – 35 mm dia. formwork / installation bits
Drilling in wood and metal using the keyless chuck and drill bits with smooth shank up to 13 mm dia.
Driving anchor screws and concrete screw anchors

Specifications

Rotation speed gear 1 under no load	750 rpm
Full hammering frequency	4080 impacts/minute
Single impact energy	2.4 ft-lbf
Hammer drill bits (optimum dia. range)	3/8 - 13/16 in
Weight according EPTA-Procedure 01/2003	8.8 lb.
Active Vibration Reduction	No
Active Torque Control	No
Dust removal module	TE DRS-S (optional)

Contact us for warranty information
